Ortofon SPU Meister Silver GM MkII Expand

Ortofon SPU Meister Silver GM MkII

Ortofon

Ny

The SPU Meister Silver GM MkII has been improved on coil winding material, stylus and magnet.

Mer detaljer

21 990 kr

inkl.

The SPU Meister Silver GM MkII has been improved on coil winding material, stylus and magnet.

The cartridge has been outfitted with high purity multi-conductor 6–nines Silver wire (of a purity of 99,9999 %) for a more open and revealing high end presentation.
The nude elliptical stylus tip mass has been decreased by a factor of more than 50%, resulting in increased tracking ability and reproduction of microdynamic detail.
The generator system has been revised to produce a slightly higher output to ensure compatibility with a wider range of moving coil transformers and active MC preamplifiers.

Technical data

Output voltage at 1000 Hz 5cm/sec - 0,3 mV
Channel balance at 1 kHz  < 1 dB
Channel separation at 1 kHz  > 20 dB
Channel separation at 15 kHz  > 10 dB
Frequency response 20 - 20 kHz  +2/-1 dB
Tracking ability at 315 Hz at recommended tracking force *)  > 70 μm
Compliance, dynamic, lateral - 8 μm/mN
Stylus type - Nude elliptical
Stylus tip radius - r/R 8/18 μm
Tracking force range - 3.0-5.0 g (30-50 mN)
Tracking force recommended - 4.00 g (40 mN)
Tracking angle - 20º
Internal impedance, DC resistance - 1.5 ohm
Recommended load impedance > 10 ohm
Coilwire material - Silver, 6-nines
Cartridge body material - Grinded wood and resin composite
Cartridge colour - Shiny black
Cartridge Weight - 32 gram

*) Typical value
