Enter the Exclusive world of Ortofon’s famous moving coil sound.

The Quintet Red is a perfect introduction to the world of Ortofon moving coils.
It features an Elliptical diamond which is cut and polished to Ortofon’s standards.

This entry-level MC cartridge has very high price-to-performance ratio and is a perfect all-rounder for the newcomers to the world of Moving Coil cartridges.

• Output voltage at 1 kHz 5 cm/sec - 0.5 mV
• Channel balance - < 1.5 dB
• Channel separation at 1 kHz - > 21 dB
• Channel separation at 15 kHz - > 14 dB
• Frequency range at -3dB - 20 - 25.000Hz
• Frequency response - 20-20.000 Hz +/-2.5 dB
• Tracking ability at 315 Hz at recommended tracking force *) - 65 μm
• Compliance, dynamic, lateral - 15 μm/mN
• Stylus type - Elliptical
• Stylus tip radius - r/R 8/18 μm
• Tracking force range - 2.1-2.5 g (21-25 mN)
• Tracking force recommended - 2.3 g (23 mN)
• Tracking angle - 20º
• Internal impedance, DC resistance - 7 Ohm
• Recommended load impedance - >20 Ohm
• Cartridge body material - ABS/Aluminium
• Coil wire material - Copper
• Cartridge colour - Red
• Cartridge weight - 9 g
